Gearbox with motor flange

Lorem Ipsum…

VC

Servo motor flange

SC

Servo motor flange

HC

Servo motor flange

LC

Servo motor flange

VL

IEC motor flange

SL

IEC motor flange

HDVL

IEC motor flange

TYPE VC

Optimized for mounting a servo motor

High speeds up to n1 = 6000 1/min - Minimized circumferential backlash (optional) - High precision - Cast iron housing

Features

  • Optimized for mounting a servo motor, the gearbox flange can be configured individually
  • Bevel gearbox with spiral toothing
  • Gear ratios: i = 1:1 to 6:1
  • Compact design
  • Low backlash design with up to < 6 angular minutes
  • Maintenance-free

Construction types

TYPE SC

Worm gearbox with servo flange

Optimized for mounting a servo motor, the gearbox flange can be configured individually

Features

  • Robust, powerful and low-noise worm gear unit
  • Vibration damping properties
  • Axis offset between input and output shaft
  • Low backlash design with up to < 6 angular minutes
  • Maintenance-free

Construction types

TYPE HC

Servo hypoid gearbox

With motor flange for servo motors

Features

  • Gear ratios: i = 3:1 to 15:1
  • Maximum acceleration torque at output 2160 Nm
  • 6 gearbox sizes from 090 to 260 mm edge length
  • Minimized backlash (optional)
  • Aluminum housing
  • Hypoid gears suitable for mounting servo motors

Construction types

TYPE LC

Miniature bevel gearbox with servo flange

Small dimensions - compact design - high precision

Features

  • Miniature bevel gearbox with spiral toothing
  • Weight reduced
  • Housing made of aluminum material, anodized version available
  • Low backlash design with up to < 6 angular minutes
  • Maintenance free

Construction types

TYPE VL

Optimized for mounting a standard IEC motor, the gearbox flange can be configured individually

bevel gearbox with spiral teeth - ratios: i = 1:1 to 6:1 - compact design - low backlash with up to < 6 angular minutes - maintenance-free

Features

  • Optimized for mounting an IEC standard motor, the gearbox flange can be configured individually
  • Bevel gearbox with spiral toothing
  • Gear ratios: i = 1:1 to 6:1
  • Compact design
  • Low backlash design with up to < 6 angular minutes
  • Maintenance-free

Construction types

TYPE SL

Worm gear unit with flange for IEC standard motor

The gearbox flange can be individually configured

Features

  • Optimized for mounting a standard IEC motor, the gearbox flange can be individually configured
  • Robust, powerful and low-noise worm gear unit
  • Vibration damping properties
  • Axis offset between input and output shaft
  • Low backlash design with up to < 6 angular minutes
  • Maintenance-free

Construction types

TYPE HDVL

With moto flange - For the pharmaceutical and food processing industries.

The choice of materials, the design and the surface finish guarantee you optimum cleaning properties and maximum hygiene. The design of all external components in stainless steel effectively prevents any form of corrosion and is also acid-resistant and alkali-resistant. The typical product qualities such as high running smoothness, high efficiency, robustness, gear accuracy are guaranteed and excellent delivery capability is a matter of course.

Features

  • The dimensions are identical with the gear units of type V
  • All external production parts are made of high quality stainless steel
  • The shaft sealing rings are designed with additional dust lip
  • The housing and the flanges do not contain any holes or other dirt pockets
  • Required mounting holes are drilled according to customer specifications
  • Surface roughness with Ra <=0,8
  • Food lubrication NOTOX

Construction types
